    AD2428WCCSZ-RL Audio A2B Transceiver 1 Channel 32-LFCSP-SS (5x5)

    Ask Lasest Price
    Brand Name : Original
    Model Number : AD2428WCCSZ-RL
    Certification : Original
    Price : Negotiation
    Payment Terms : TT
    Supply Ability : 100
    Delivery Time : 3-4days
    • Product Details
    • Company Profile

    AD2428WCCSZ-RL Audio A2B Transceiver 1 Channel 32-LFCSP-SS (5x5)

    ADXL345 Accelerometer X, Y, Z Axis ±2g, 4g, 8g, 16g 0.05Hz ~ 1.6kHz 14-LGA (3x5)


    Specifications of AD2428WCCSZ-RL
    TYPEDESCRIPTION
    CategoryIntegrated Circuits (ICs)
    Audio Special Purpose
    ManufacturerAnalog Devices Inc.
    Series-
    PackagingTape & Reel (TR)
    Cut Tape (CT)
    FunctionAudio Transceiver
    ApplicationsAudio
    Number of Channels1
    InterfaceI2C, I2S
    Voltage - Supply3V ~ 3.63V
    Operating Temperature-40°C ~ 105°C
    Specifications-
    Mounting TypeSurface Mount, Wettable Flank
    GradeAutomotive
    Package / Case32-WFQFN Exposed Pad, CSP
    Supplier Device Package32-LFCSP-SS (5x5)
    Base Product NumberAD2428


    A2B TRANSCEIVER FEATURES of AD2428WCCSZ-RL


    Configurable A2B bus master or slave operation
    I2C interface
    8-bit to 32-bit multichannel I2S/TDM interface
    Programmable I2S/TDM data rate
    Up to 32 upstream and 32 downstream channels
    PDM interface
    Programmable PDM clock rate
    Up to 4 high dynamic range microphone inputs
    Simultaneous reception of I2S data with up to 4 PDM
    microphones
    Unique ID register for each transceiver
    Crossover or straight-through cabling
    Programmable settings to optimize EMC performance


    Applications of AD2428WCCSZ-RL


    Audio communication link
    Microphone arrays
    Beamforming
    Hands free and in car communication
    Active and road noise cancellation
    Audio/video conferencing systems



    Environmental & Export Classifications of AD2428WCCSZ-RL


    ATTRIBUTEDESCRIPTION
    RoHS StatusROHS3 Compliant
    Moisture Sensitivity Level (MSL)3 (168 Hours)
    REACH StatusREACH Unaffected
    ECCNEAR99
    HTSUS8542.39.0001
