AC220V Handheld Automatic Cable Tie Bundle Machine For Oven Wire Harness

Automatic bundle machine for nylon zip ties! Fast Automatic bundle, 0.7S every cable tie!

SWT25100H Specifications

SWT25100H Features

1. Using nylon cable ties, width2.5mm and length100mm, loose nylon cable ties.

2. With a handheld cable tie gun. Easy to hold and operate.

3. Once push the trigger, the cable tie gun would start to bundle, tighten and cut nylon cable ties. All actions take 0.7S.

4. The rubbish would be collected into a box.

5. The bundled items diameters: Ø2mm - Ø18mm.

6. Binding forces can be adjusted by turning the knob.

7. SWT25100H is with a handheld cable tie gun. And It can be also used as a fixed cable tie gun. It needs some alloy supports and other extra parts to achieve this function.

8. It be applied to full automation line too.

Important detais

You could know the important details of specifications chart. Pls talk more the voltage and the pneumatic pressure.

The automatic cable tie machine voltage is AC220V – AC240V,50/60Hz.And it must use the air source.

Most factories have the air sources. It is no problem to use this machine in these factories.

The pneumatic pressure is 5kg/cm².When to use the tie wrap machine, it is suitable for 3 – 5kg/cm².

Before the machine is shipped, our engineer has set the specifications already.

Package

Be packed in wooden cases. The host machine and handheld cable tie gun will be packed in a wooden case. The vibration bowl will be backed in the wooden case.

Other products

FAQ

1. Can I use other nylon cable ties in this machine?

No, you can't. One machine can only use one kind of nylon cable ties.

2. What is the warranty?

1 year warranty and tech support forever.

3. What should I do if the machine alarms?

The machine would stop working and would give tips in the home screen. So pls check the tips and deal with the problems. Or pls contact our team to help you.

Productronica 2019

Shenzhen Swift Automation Technology Co., Ltd. is located in the BaoAn District of Shenzhen City,12 KM to the Shenzhen Airport and near the New Convention and exhibition center. Our business majorly covers 2 aspects:

1. Automatic Nylon Cable Tie machine and its supporting equipments.
2. Nylon Cable Ties.

We have a very strong design team, most of the engineers graduated from the renowned military institution, such as HIT,Beijing Institute of Technology, Shenyang Aerospace University, worked as weapon designer for many years, and got trained and worked in Switzerland, Germany, Austria, and Czech Republicas for auomation design for years; Served as senior engineer and senior engineering manager in a number of large multinational enterprises (Vitech, Microsoft, Foxconn, Flextronics, TE, Whirlpool, etc.). Most of our assembly engineers come from丿apanese automation companies. Obtained European design conception and skill, with Japanese quality sense to control the manufacturing process, we can provide you the best technical solution and reliable product quality.
SWIFT--- will be becoming the world's top brand of nylon cable tie and the tools maker, with more than 50 inventions patents as well as multiple software Copyrights. Not only in dominant position in China market, our products have been sold to more than 30 countries and regions (such as United States, Netherlands, Mexico, Japan, South Korea, Turkey, Romania, Italy ... highly developed countries}, with nearly 400 customers in worldwide.

Our target: Internationalization, branding, specialization .
