Handheld Nylon PA6.6 0.9S Automatic Cable Tie Machine
Automatic cable tie gun can bundle single cable tie in 0.9S so it
can tie 2,000pcs – 3,000pcs nylon zip ties. An electric cable tie
gun can save 2 or 4 workers.
Feature of nylon cable tie gun
1. Automatic cable tie gun is a handheld type. Operator can move it
easily. Operable distance is 2.2m.
2. The electric cable tie gun can thread, tighten and cut off nylon
cable ties once operator pulls the trigger.
3. The waste can be collected into a tank or a box.
4. Vibration bowl capacity: 200 – 300pcs/time. Worker keeps the
bowl having the qty.
5. PLC control system , touch screen: multi-langue
6. Voltage: AC220, 50/60Hz; pneumatic pressure: 5kg/cm²
Specification of automatic cable tie tool
| Model | SWT36120H |
| Applicant cable ties | T36120 |
| Cable tie size | W3.6 * L120mm |
| Cable ties material | Nylon PA6.6 |
| Min banding Dia. | Ø2 mm |
| Max banding dia. | Ø23 mm |
| Operation speed | 0.9S/cable tie |
| Electrical power | Host: AC 220V, 50/60 Hz |
| Handheld tie gun: DC 24V(automatic switching) |
| Pneumatic pressure | 5 Kg/ cm² |
| Power | 1,000W |
| Maximum tension force | 2 – 8kg adjustable |
| Productivity | 1200 - 1500pcs./h |
| Weight | Host:160 kg with wheels |
| Tie gun: 0.88kg |
| Size | Host: L890 * 900 * 790mm |
| Gun: L247 * W73 * H74mm |
| Certificate | CE & RoHS |
Application of nylon cable tie machine
1. Military industry: Camouflage net bundle or explosives bundle
2. Appliance industry: internal wire harness management in
appliance, such as oven, washing machines, air conditioning etc.;
3. Photovoltaic industry: terminal box of the photovoltaic status
indicator/solar junction boxes;
4. Wire harness industry: wire harness management;
Advantage of automatic cable tie machine
1. Bundle a cable tie takes 0.9S. It is faster than by-hand.
2. Cable tie gun can bundle the objet with different diameters as
long as it is less than the max D. 23mm.
3. An automatic cable tie gun can finish tying about 1,500pcs cable
ties in a hour, if adding the time of picking the object up and
putting it in the middle of tie gun jaws.
4. One automatic cable tie machine can save 2 workers even more.
5. Bundle forces are adjustable by turning a knob in the tie gun.
6. There is a handheld cable tie gun. If you add a metal support,
the tie gun can be as a fixed tie gun.
7. Could be applied to full automation line.
About packing
| The host machine for SWT36120H | *1 |
| The vibration bowl for SWT36120H | *1 |
| The handheld cable tie gun for SWT36120H | *1 |
| The tool kit | *1 |
| The English manual | *1 |
The host, the cable tie gun and the tool kit would be packed in a
wooden case.
The bowl would be packed in a wooden case.
| Item | Packing size | G.W./kg | N.W./kg |
| The host and others | 80*80*90cm | 100kg | 74kg |
| The bowl | 70*60*70cm | 77kg | 60kg |
About delivery
1. Lead time for machine: 15days
2. Lead time for nylon cable ties: 10days
3. 1 year warranty and tech support forever.
FAQ
1. How do I adjust the binding force?
In the cable tie gun, there is a knob to spin. And there is a small
window to display the force values.
2. Do you have automatic cable tie machine that can deal with auto
cable tie clips?
No, our machines can bundle some general cable ties. The heads of
them look like rectangle.
3. Does the automatic cable tie machine need air?
Yes, it asks for pneumatic pressure 5kg/cm²
