Fixed type 1200pcs/H 1KW Automatic Cable Tie Machine
Automatic cable tie machine can bundle single cable tie with 1.3S.
It can save workers’ cost and time.
Features of automatic cable tie gun
1. Use reel cable ties, width 3.6 * length 200mm, 4,000pcs cable
ties per reel.
2. The automatic cable tie gun is triggered by the foot pedal so
two hands of operator are free.
3. Operator doesn’t have to load cable ties often because there are
4,000pcs in a reel.
4. Once worker treads the foot pedal, cable tie would be
automatically bundled and the waste of cutting nylon ties off would
be collected into a box.
5. Operator can adjust the bundle forces by turning a knob of tie
gun.
6. The automatic cable tie gun can bundle products’ outer diameter
up to 42mm because of 200mm length nylon cable ties.
7. The automatic cable tie gun needs the electricity and air
source.
8. Option: a big frame support to fix the tie gun.
Technical data of nylon cable tie machine
| Model | SWT36200FC | Bundle speed | 1.3S/pcs |
| Applicant cable tie model | C36200 | Bundle productivity | 1200pcs/h(Including auxiliary time) |
| Applicant cable tie size | W3.6 * L200 * T1.2mm | Power | 1KW |
| Bundle diameter for wire harness | 15mm – 42mm | Voltage | AC220V, 50/60Hz |
| Bundle diameter for tube | 15mm – 40mm | Pneumatic pressure | 5kg/cm² |
Application of automatic cable tie system
| 1. Electrical industry | Coils of polyester monofilaments, wire harness etc. |
| 2. Home appliance | Copper tubes with insulation glue, capacitor component on washing
machine etc. |
| 3. Food industry | Crabs, Oyster etc. |
Advantages of automatic tie wrap machine
1. High reliability: 99.9%-99.99%
2. 100% components in the tie gun are made of high hardened steel,
no plastic parts.
3. Offer 1 year warranty and tech support forever.
4. An automatic cable tie gun can save 2 workers and save much
time.
5. The tie gun can installed in the assembly line and meet the
requirements of production line.
6. The waste after cutting nylon cable ties can be collected into a
box. They would not be thrown anywhere.
7. The automatic bundle machine is easy to operate and work stable.
About packing
| NO | The host, tie gun and others | The bowl | Nylon cable ties C36200 |
| Package | Wooden case | No | Carton box |
| Qty | 1pcs | No | 1pcs |
| Packing size | 95*58*110cm(include the big frame to fix tie gun) | No | 47*47*48.5cm |
| G.W./kg | 84kg | No | 10kg |
| N.W./kg | 64kg | No | 7kg |
| Picture |  | |  |
About delivery
1. Lead time for automatic cable tie machine: 10-15working days
2. Lead time for reel cable ties: 10days
3. It is no problem to ship by air or sea.
FAQ
1. Does cable tie gun deal with twisted wire?
No, cable tie gun can only deal with nylon zip ties.
2. Do I need to remove reel cable ties if they are not run out?
No, you don’t but please use a bag to seal reel cable ties. Nylon
cable ties are easy to loss and absorb moisture that would impact
their optimum performance.
3. Must cable tie gun run in air source?
Yes, it asks pneumatic pressure 5kg/cm².
4. Do you have an English manual?
Yes, all machines have English manual.
