Fast Bundle 0.8S Speed 22mm Max Diameter Wire Harness Automatic
Wire Tying Tool
Pull the trigger of cable tie tensioning gun, cable tie is pulled
tightly, cut the exccess tail and collect the waste material into a
box.
All steps take about 0.8S. You can save at least 2 -4 workers.
Automatic Wire Tying Tool advantages
1. Use loose cable ties T25120, width 2.5mm * Length 120mm
2. Ergonomic cable tie gun is comfortable to hold and operate.
3. Bundle Max diameter for wire harness is 22mm, 21mm for tubes.
4. The binding force is adjusted.
5. Power supply: AC220 – AC240V, 50/60Hz; Euro standard plugs.
6. Auto cable tie machine is easy to move.
Cable tie hand tool parameters
| 1 | Cable tie hand tool – SWT25120H |
| 2 | Description | Automatically wrap, pull and tighten cable ties, cut the excess zip
ties off and collect them into a box. |
| 3 | Cable tie type | Bulk zip ties |
| 4 | Cable tie size | width | 2.5mm |
| Length | 120mm |
| Tie thick | 1.2mm |
| 5 | Tensile strength | 12kg |
| 6 | Bundling diameter | Ø2 –ø22mm |
| 7 | Operation speed | 0.8S |
| 8 | Power supply
| AC220-240V, 50/60Hz |
| 9 | Pneumatic pressure | 5 Kg/cm² |
| 10 | Tension force | Adjustable |
| 11 | Power | 1000W for the host machine; DC24V for the handheld tie gun(When auto cable tie machine is
working, pls don't pull the tie gun out directly!!!!) |
Packing details
| Packing details of SWT25120H |
The whole machine / wooden case
| G.W./kg | 158kg |
| N.W./kg | 132kg |
| Packing Size/cm74kg( estimated) | L75 * W75 * H80cm |
Applications
| Applications | The machine bundles objects with cable ties tightly. |
| Wire harness industry | Wirings in boards, power cords, waterproof rings, PCB boards |
| Solar energy | Photovoltaic junction box, wires |
| White goods | AC component, copper pipe with insulation cotton, air-conditioning
condenser pipes, fridge condenser pipes, the clumps etc. |
| Medical industry | Medical hoses, the connectors. |
| Auto industry | Auto parts with wires |
| Others | Fishing net, trinkets etc. |
FAQ
1. What is the warranty?
1 year, tech support all life.
2. How could I select automatic cable tie tools?
Pls measure the bundle max diameter for your products. It is
different if you bundle wire harness or tubes. Pls contact our
sales to get more details.
3. Now, what max diameter does your cable tie machine bundle?
Up to 70mm. You could know SWT36300HC or SWT36300FC.
4. Do you have tech support departments in other countries?
No, we don't have. If have any problems, pls contact us any time
and we can help you to solve them.
